中文简体Automotive R-Type spring split pins are simple yet effective fasteners used to secure components such as clevis pins, axles, or shafts in automotive and industrial applications. These pins feature a looped end (the "R" shape) and two straight legs that are designed to be inserted through a hole in a component. The spring tension of the legs ensures that the pin remains securely in place, preventing unintended disassembly.The two legs of the R-type pin are slightly bent outward, creating spring tension that holds the pin securely in place once inserted. This design provides a reliable locking mechanism without the need for additional tools or hardware.The looped end serves as a handle for easy installation and removal. It also prevents the pin from being fully pulled through the hole, ensuring it stays in place during operation.R-type pins can be installed quickly by hand or with minimal tools, making them ideal for applications where speed and simplicity are important.
Designed for Ease of Use:
We prioritize efficiency in your assembly processes. The distinct looped end of our R-Type pins not only acts as a convenient handle for effortless installation and removal by hand or with minimal tooling but also serves as a crucial stop feature. This prevents the pin from being accidentally pulled entirely through the securing hole, ensuring consistent and reliable fastening during operation.
Key Advantages for Your Applications:
- Reliable Locking Mechanism: Spring tension ensures secure fastening and prevents accidental disassembly.
- Effortless Installation & Removal: Designed for quick and simple handling, reducing assembly time.
- Integrated Stop Feature: The looped end prevents over-insertion and ensures the pin stays in place.
- Versatile Applications: Ideal for securing clevis pins, axles, shafts, and various other components in automotive and industrial machinery.
- Durable Construction: Manufactured from high-quality spring steel for long-lasting performance and resilience.
- Cost-Effective Solution: Offers a simple yet highly effective fastening solution without the need for complex tooling or additional hardware.
- Available in a Range of Sizes and Materials: [Mention specific material options like carbon steel, stainless steel, and available size ranges to cater to diverse application needs].
Ideal for:
- Automotive assembly lines
- Agricultural machinery
- Construction equipment
- Industrial machinery and automation
- Securing linkages and pivot points
- Quick-release mechanisms
| Product name | Standard | Material | Diameter | Length |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 1.5 mm | 30 mm |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 2 mm | 50 mm |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 3 mm | 60 mm |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 4 mm | 80 mm |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 5 mm | 100 mm |
| R type spring cotter Pins | GB/T 879.1-2000 | 65Mn Steel, Galvanized | 6 mm | 120 mm |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 1/16" | 1-1/4" |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 5/64" | 2" |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 3/32" | 2-1/2" |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 1/8" | 3" |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 5/32" | 4" |
| R type spring cotter Pins | ASME B18.6.3 | SAE J178, Zinc Plated | 3/16" | 5" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.0625" | 1.25" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.0787" | 1.97" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.118" | 2.36" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.157" | 3.15" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.197" | 4.33" |
| R type spring cotter Pins | ANSI B18.6.3 | ASTM A228, Zinc Plated | 0.236" | 4.72" |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 1.4 mm | 32 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 2 mm | 50 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 3 mm | 58 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 3 mm | 60 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 3 mm | 75 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 3 mm | 80 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 3.5mm | 62 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 4 mm | 60 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 4 mm | 80 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 4 mm | 85 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 4 mm | 115 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 4.5 mm | 100 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 5 mm | 85 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 5 mm | 110 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 5 mm | 135 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 6 mm | 105 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 6.3 mm | 115 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 7 mm | 105 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 8 mm | 110 mm |
| R type spring cotter Pins | DIN 11024 E | Spring Steel, Galvanize | 8 mm | 140 mm |
